Quick Details

  • Place of Origin: Guangxi, China (Mainland)
  • Brand Name: YUCHAI
  • Model Number: YLGF-80
  • Output Type: AC Three Phase
  • Speed: 1500, 1500rpm
  • Frequency: 50Hz/60hz
  • Rated Power: 80kw/100kva
  • Rated Voltage: 400V/230V
  • Rated Current: 144A
  • Net weight: 1350kg
  • Overall Dimension(L*W*H)(mm): 2350*1000*1550
  • Power range: 15kw-500kw
  • Type: open type, silent type, trailer type
  • Cooling System: Closed cycle water-cooled with fan,water tank
  • Certificate: CE, ISO9001
  • Fuel Consumption(g/kw.h): 203
  • Cylinder number: 6
  • Applications: hospital,mine, tall building, bank, school, factory, railway

Packaging & Delivery

Packaging Details Standard Export Package, Wooden Package,or Packed On Pallet
Delivery Time 30 days

100kva silent generator diesel genset

Product Description



Features of 100kva silent generator diesel genset

1.good technical performance indicators;

2.low noise, low emission and low oil consumption;

3.power reserve, and has good technical performance indicators;

4.high temperatures and rotating parts complete protection;

5. CE certificate;



 Parameter of 100kva silent generator diesel genset



GensetGenset Model YLGF-80
 Rated Power  (kw/kva)75KW
100KVA
Rated Voltage (Volt)400V/230V
Rated Current (Amp)144A
Rated Frequency (Hz)50
Rated Speed (RPM)1500
Power Factor / PhaseCos 0.8 Lagging, 3 phase
Cooling SystemClosed cycle water-cooled with fan,water tank
Overall Dimension (L×W×H)(mm)2350*1000*1550
Net Weight (kg)1350KG
Diesel
Engine
Engine BrandYUCHAI
Engine ModelYC6B135-D20
Prime Power (kw)99KW
Engine Structure6 Cylinder,Vertical,Inline,Four stoke
Bore×Stroke (mm)108×125
Fuel SystemMonomer pump
Fuel Consumption (g/kw.h)203
Rotating Speed (RPM)1500
Speed Governing EFC electronic speed governor
Starting MethodBy 24V batteries
AlternatorAlternator BrandYINGLI
Alternator ModelYLW-75
FeaturesBrushless, self-excitation, AVR regulation,
IP23 protection grade
Insulation ClassClass H
 Steady Voltage Regulation≤ +/- 0.1%
Instant Voltage Regulation-15%~+20%
Voltage Fluctuation Rate≤ +/- 0.5%
 Steady Frequency Regulation≤ +/- 0.5%
Instant Frequency Regulation-7%~+10%
Phase/Connection Type3 phase 4 wire/Y type







Details of 100kva silent generator diesel genset



1. Famous brand engine can be chosen by buyer.

2.Spray public chassis;The filters and control panel.

3.Easy to be assembled or disassembled.

4. High-performance shock absorbers and 40 °C hot tank;

5. Control Panel:High water temperature, low oil pressure, low speed and over load protectio









Applications of 100kva silent generator diesel genset

The gensets are used for:hosipitals,malls,offices,tall buildings,cinemas,mines and etc. as uninterrupted power supply and standby, common power supply.





Packaging & Shipping

Standard Standard Export Package, Wooden Package,or Packed On Pallet.









Our Services



1. Free technical enquires
2. Free repairs during warranty
3. Free operation and repair training
4 .Free maintenance service


 Company information



Our company is a leading exporter of construction machinery.

All machines are in strict standard inspection from research to manufacture.

Our head office is located in Nanning, China-ASEAN international trade center.



Our customers



With good quality and excellent after-sale service,our products are popular at home and abroad, and have been exported to more than 180 countries in South East Asia, the Middle East, Latin America, Africa and East Europe.
You are always welcomed to visit our company and workshop!
