Quick Details

  • Condition: New
  • Usage: Boat
  • Fuel: Diesel
  • Stroke: 4 Stroke
  • Cylinder: Multi-cylinder
  • Cold Style: Water-cooled
  • Start: Electric Start
  • Place of Origin: Guangxi, China (Mainland)
  • Brand Name: Yuchai
  • Model Number: YC6A200C
  • Dimension(L*W*H): 1415x291x1075
  • Weight: 770Kg
  • Certification: ZC,CCS
  • Warranty: One year
  • After-sales Service Provided: Overseas service center available
  • Displacement: 7.252
  • Color: as requested
  • Min specific fuel consuption: ≤198
  • Specific oil consumption: ≤0.8
  • Intake way: Turbo charging and inter-cooled
  • Matched reduction gearbox: 120C,135,MB242etc
  • Compression ratio: 17:1
  • Crankshaft rotation direction: Anticlockwise
  • Flywheel: SAE11.5
  • Flywheel cover: SAE2

Packaging & Delivery

Packaging Details Standard Export Package, Wooden Package,or PACKED ON PALLET

fishing boat 200hp small inboard marine diesel engine

Product Description









Features of fishing boat inboard marine diesel engine

1.Muti-technology fushion of technologies of FEV and Yuchai advanced technology

2. Compact construction, smaller weight and higher reliability

3. ideal power for small ship and fishing vessels





Parameter of inboard marine diesel engine

Engine ModelYC6A280-C20YC6A260-C20YC6A250-C20
Intake wayTurbocharged. inter-cooled
TypeVertical , in-line, water-cooled, 4-stroke
cylinder/Bore*Stroke(mm)6-108*132
Displacement(L)7.252
Compression Ratio17:1
Continuous Power/Speed(kW/r/min)206(280)/2500191(260)/2300183(250)/2200
1-hour Power/Speed(kW/r/min)227(310)/2580210(285)/2374201(280)/2270
Min. fuel consumption(g/kW.h)≤198
Lubricant Oil Consumption (g/kW·h)≤0.8
Crankshaft Rotation Direction(facing power output end)counterclockwise
Net Weight(kg)780
Overall Dimension (L*W*H)(mm)1430*900*980
Gearbox to be matched120C,HCQ138,etc.
CertificateZC/CCS/IMO







  Installation Drawing of fishing boat inboard marine engine



Application of inboard marine diesel engine

1. Fishing boat

2. Passanger boat

3. Small cargo ship



Do you need gearbox for the engine ?











How to select gearbox for the engine ?

Different ships have different gearbox ratio and different diameter of the propeller. The gearbox reduction ratio and the propeller diameter of cargo boats and fishing boats are relatively larger than passenger ships and public service ships.



The gearbox ratio of ships (the recommended reference)



Types of shipCargo shipFishing boatTrawlerHigh-speed public service ship
without trawl
Diesel engine of rated speed 1500r/min4:1~5:14.5:1~5.5:15:5~7:1N/A
Diesel engine of rated speed 1800r/min4.5:1~5.5:15:1~6:16:1~8:12:1~3:1
Diesel engine of rated speed above 2100r/minAbove 5:1N/AN/A2:1~3:1





What is the application of our engine ?

Recommended applications of YUCHAI marine engine series

YC6A170C125/1500commercial ship, passenger ship, fishing boat
YC6A190C140/1800commercial ship, passenger ship, fishing boat
YC6A195C145/2300continued running time more than 12hours a day
YC6A220C162/2300continued running time less than 8hours a day





How to test our engine?

The engine is suitable for High temperature/high-pressure/ extremely cold condition







Packaging and shipping

Standard Export Package, Wooden Package,or Packed On Pallet.









Our service

1.Fast and sincere service with more than 100 overseas service agents
2.The most professional technical support with a 24hour uninterrupted service

Company Information

1.Professional  factory with more than 60 years experiences in diesel engines.
2.Professional scientists and engineers.
3.Strict testing process.

Our customers
With good quality and excellent after-sale service,our products are popular at home and abroad, and have been exported to more than 180 countries in South East Asia, the Middle East, Latin America, Africa and East Europe.
You are always welcomed to visit our company and workshop!
